CP-RIO6-001

Name: CP-RIO6-001
SKU: 88711

4HP Rear I/O interface for a 6U CompactPCI CP6002, CP6003, CP6004, CP6005, CP6006 processor board

Product Information

The CP-RIO6-001 is a 4HP Rear I/O interface for a CP6002, CP6003, CP6004, CP6005, CP6006 CompactPCI card complying to Kontron\'s proprietary RTM pinout rev 1.11. This RTM unit will provide USB, Ethernet, serial, DVI-D/HDMI, USB Flash, and SATA connection as well as the option to place a SATA 2.5\' HDD.
3 versions are available:
1. Hard disk socket for 2.5 inch HDD /SSD
Rear panel: 1xDVI/HDMI, 2xUSB, 2xEthernet
2. No hard disk socket
Rear panel: 2xDVI/HDMI, 2xUSB, 2xEthernet
3. Hard disk socket for 2.5 inch HDD / SSD
Rear panel: VGA, 2xUSB, 2xEthernet

Coming soon: Rear transition module for triple display outputs. Rear panel: VGA + 2xDVI/HDMI, 2xUSB, 2xEthernet, no 2.5 inch HDD/SSD socket,

Technical support

Technical data

Mouse	n/a
Keyboard	n/a
SATA	2x SATA connectors
Serial	1x RS232, 1x RS422 on headers
Video Output	1x DVI-D/HDMI, optionally 2x DVI-D/HDMI (option), optionally 1x VGA
