cPCI 6U DC 350W

The cPCI 6U DC 350W is a CompactPCI (cPCI) power supply module designed for DC input operation, delivering up to 350 W of power in a 6U form factor.

Specifications

Hot-swap capable, redundancy and current share support
Wide DC input (18–72 VDC)
Four output rails with high current capacity
Over-temperature protection and status signaling
Air cooling with required minimum airflow
CompactPCI format with front extractor handle
Fully compliant with PICMG 2.11 standard

Download Datasheet

It supports hot-swap, redundancy, and current sharing, fully compliant with PICMG 2.11 power supply standards.

The cPCI 6U DC 350W module provides reliable DC power for CompactPCI systems used in industrial and embedded environments. Supporting a wide DC input range of 18–72 V, it is suitable for telecom, transportation, and defense applications. Its high output capability, redundancy, and hot-swap functionality ensure stable and continuous operation. Integrated protection features and clear LED indicators enhance system safety and diagnostics.

Features

Form Factor: 6U × 8HP, CompactPCI format, 160 mm deep

Input: 18–72 VDC wide range

Efficiency: ~85 % typical

Output Rails & Currents:
• +5 V: 40 A
• +3.3 V: 40 A
• +12 V: 10 A
• –12 V: 2 A

Operating Temperature: –40 °C to +70 °C (with derating)

Storage Temperature: –40 °C to +85 °C

Cooling: Air cooling required; at least 400 LFM airflow

Connectors: P47 (47-pin) for outputs/management

Protection & Control: Hot-swap, redundancy, current share bus, over-temperature protection, “status” LED (bi-color)

Part Number: D575.00354
