cPCI 3U AC 300W

The cPCI 3U AC 300W is a CompactPCI (cPCI) power supply module with wide-range AC input, delivering up to 300 W in a 3U form factor with 8HP width; it supports hot-swap, redundancy, and current share bus, fully compliant with PICMG 2.11.

Specifications

Hot-swap capable, redundancy and current share support
Wide AC input (90–264 VAC)
Four output rails with high current capacity
Efficiency ~85 % typical
Air cooling with required minimum airflow (400 LFM)
CompactPCI format 3U × 8HP with front extractor handle
Fully compliant with PICMG standard

Download Datasheet

The cPCI 3U AC 300W module offers a reliable, rugged AC-input power supply solution for CompactPCI systems used in industrial, telecom or defence environments. With its wide input voltage range of 90–264 VAC, strong output rails, and support for hot-swap and redundancy, it is ideal for high-availability systems. The format and build quality ensure full compliance with the PICMG standard and the robust design supports demanding operating conditions.

Features

Form Factor: 3U × 8HP, CompactPCI format, 160 mm deep.

Input: 90-264 VAC wide range.

Outputs: +5 V/40 A, +3.3 V/40 A, +12 V/10 A, –12 V/2 A.

Efficiency: ~85 % typical.

Operating Temperature: –40 °C to +70 °C (with derating).

Storage Temperature: –40 °C to +85 °C.

Cooling: Air cooling required; at least 400 LFM airflow.

Connector: P47 47-pin for outputs/management.

Protection & Control: Hot-swap, redundancy, current share bus, status LED (bi-colour).

Part Number: D575.00361.
