VME64x 7U 84HP 17 Slots
The VME64x 7U/84HP 17 Slots chassis by Hartmann Electronic is a high-capacity, 19" rack-mountable solution designed for industrial applications.
Spezifikationen
- Form Factor: 7U height, 84HP width
- Dimensions: Height: 12.3 cm, Width: 42.0 cm, Depth: 28.3 cm
- Slots: 17 slots (16x 6U VME64x, 1x 3U power)
- Backplane: Monolithic design with J0 connectors, automatic daisy chain/bus grant, active termination, and 2x P47 connectors
- Cooling: Fixed fan tray with 3 axial fans (120mm, 120CFM each, 48 dB(A))
- Airflow Direction: Bottom to top
- Power Supply: Type: 2x 400W cPCI hot-swap
- Input: 90–264V AC, 47–63Hz
- Output Voltages: +3.3V / 55A, +5V / 55A, +12V / 14A, -12V / 4A
- Mounting: 19" rack-mountable
- Compliance: Conforms to VITA 1.1-1997, IEEE 1101.1 and 1101.10/11, IEC 60297-3-101, -102, -103
The VME64x 7U/84HP 17 Slots chassis offers a high-capacity solution for industrial applications requiring a 19" rack-mounted platform. Its monolithic backplane design and dual hot-swap power supplies ensure reliable performance, while the fixed fan tray provides effective cooling. This chassis is ideal for applications where high performance and scalability are essential.
Eigenschaften
| Capacity | High-capacity 7U height for extensive module configurations |
| Backplane | 17-slot monolithic backplane supporting 6U VME64x modules |
| Hot Swap | Dual hot-swap 400W cPCI power supplies |
| Fan | Fixed fan tray with 3 axial fans for efficient cooling |
| Standard | Conforms to international standards |
