6U VME 395 Mini Chassis
Portable 5-slot NIM crate with 150 W linear regulated power supply for mobile and compact nuclear electronics applications.
- Hot-swappable redundant plug-in power supplies (1–2 × 250 W cPCI units)
- Outputs: +5 V, ±12 V, +3.3 V (depending on PSU configuration)
- 9 slots (1 system + 8 user slots)
- 6U height, 19″ rack-mount or desktop design
- High-performance DC blower fan, speed and temperature controlled
Produktinformationen
The VME 395 Mini Crate is a compact and robust 19″ chassis for up to 9 VME modules (1 system and 8 user slots). It features hot-swappable, redundant 250 W cPCI plug-in power supplies to ensure continuous operation even under fault conditions. Cooling is provided by a high-performance, temperature-controlled DC blower, while the integrated WIENER CML shelf manager allows full monitoring and remote control of voltages, currents, fans, and temperatures via Ethernet and USB. With its modular 6U form factor, rugged construction, and advanced protection features, the VME 395 Mini Crate is ideally suited for demanding research and industrial environments requiring high reliability and flexible power distribution.
Technische Daten
| Features | Compliant with VME standard (ANSI/VITA) 9-slot configuration (1 system + 8 user slots) Redundant hot-swappable 250 W cPCI power supplies 6U height, available for rack-mount or desktop use Remote monitoring and control via Ethernet/USB shelf manager Rugged steel chassis with advanced cooling for long-term reliability |
|---|
Downloads
Handbücher
General Safety Instruction
628.88 KB | 26. März 2026
Varianten
Varianten hier auswählen
NIM_150P_X
5 Slots, ±6 V/5 A, ±12 V/3 A, ±24 V/1.5 A, 115 VAC/0.25 A, 150 W (UEP15)
The VME 395 Mini Crate is a compact and robust 19″ chassis for up to 9 VME modules (1 system and 8 user slots). It features hot-swappable, redundant 250 W cPCI plug-in power supplies to ensure continuous operation even under fault conditions. Cooling is provided by a high-performance, temperature-controlled DC blower, while the integrated WIENER CML shelf manager allows full monitoring and remote control of voltages, currents, fans, and temperatures via Ethernet and USB. With its modular 6U form factor, rugged construction, and advanced protection features, the VME 395 Mini Crate is ideally suited for demanding research and industrial environments requiring high reliability and flexible power distribution.
