SoM SL i.MX6ULL/UL
Complex Application Processor as Easy to Use as a Microcontroller
- NXP i.MX6 ULL, 1x Arm® Cortex®-A7 @800 MHz
- NXP i.MX6 UL, 1x Arm® Cortex®-A7 @528 MHz
- Up to 512 MByte RAM and up to 512 MByte NAND-Flash
- 2x 10/100 Mbit/s ETH, 1x PHY included, 1x CAN 2.0 B
- Form factor 25 mm x 25 mm
Product Information
The SL i.MX6 ULL/UL from Kontron Electronics is a compact yet powerful embedded module. By combining modern processor architecture with versatile communication interfaces and flexible software integration, the product offers a future-proof platform for a wide range of applications. Its user-friendly design enables fast and straightforward integration into existing systems – making it ideally suited for innovative solutions in automation, control, and IoT environments.
Performance & Architecture
The SL i.MX6 ULL/UL is based on a high-performance application processor from the NXP i.MX6 family and combines power with ease of use. Equipped with an Arm® Cortex®-A7 processor – optionally up to 800 MHz (i.MX6 ULL) or 528 MHz (i.MX6 UL) – the system delivers robust computing power for demanding embedded applications. Despite its performance, operation is as intuitive as with a classic microcontroller, which significantly simplifies development and integration. The system runs on Embedded Linux (Yocto Distribution) and can optionally be extended with CODESYS® SoftPLC for flexible automation solutions.
Communication Interfaces
For optimal connectivity, the SL i.MX6 ULL/UL features two 10/100 Mbit/s Ethernet interfaces, one of which comes with an integrated PHY. In addition, there is one CAN 2.0 B interface available, enabling reliable communication with other controllers and devices. Thanks to these versatile communication options, the module is ideally suited for use in complex network environments and allows seamless integration into existing system landscapes.
Areas of Application & Advantages
The SL i.MX6 ULL/UL is designed for a wide range of industrial and commercial applications where maximum performance, reliability, and flexibility are required. Typical areas of use include automation technology, industrial control systems, IoT applications, as well as embedded systems in building and transport technology. Key advantages include its compact form factor (25 mm x 25 mm), high energy efficiency, and straightforward integration. The combination of a powerful processor, versatile interfaces, and flexible software support makes the SL i.MX6 ULL/UL the ideal choice for innovative embedded solutions.
Services & Add-ons
Advantages of Kontron Electronics System-on-Module (SoM)
Fast time to market: Proven, pre-developed solution reduces development costs and accelerates project implementation.
Easy integration: Ready-developed CPU core can be used as a microcontroller.
Integrated design advantages: Prefabricated pin multiplexing and DDR3/DDR4 RAM streamline complex hardware designs.
Certified EMC safety: Decoupling capacitors and impedance-controlled cables ensure signal quality and EMC compliance.
Long-term availability: Technical support and lifecycle management throughout the entire product lifecycle.
