cPCI 3U AC 300W
The cPCI 3U AC 300W is a CompactPCI (cPCI) power supply module with wide-range AC input, delivering up to 300 W in a 3U form factor with 8HP width; it supports hot-swap, redundancy, and current share bus, fully compliant with PICMG 2.11.
Specifications
- Hot-swap capable, redundancy and current share support
- Wide AC input (90–264 VAC)
- Four output rails with high current capacity
- Efficiency ~85 % typical
- Air cooling with required minimum airflow (400 LFM)
- CompactPCI format 3U × 8HP with front extractor handle
- Fully compliant with PICMG standard
The cPCI 3U AC 300W module offers a reliable, rugged AC-input power supply solution for CompactPCI systems used in industrial, telecom or defence environments. With its wide input voltage range of 90–264 VAC, strong output rails, and support for hot-swap and redundancy, it is ideal for high-availability systems. The format and build quality ensure full compliance with the PICMG standard and the robust design supports demanding operating conditions.
Features
| Features | Form Factor: 3U × 8HP, CompactPCI format, 160 mm deep. Input: 90-264 VAC wide range. Outputs: +5 V/40 A, +3.3 V/40 A, +12 V/10 A, –12 V/2 A. Efficiency: ~85 % typical. Operating Temperature: –40 °C to +70 °C (with derating). Storage Temperature: –40 °C to +85 °C. Cooling: Air cooling required; at least 400 LFM airflow. Connector: P47 47-pin for outputs/management. Protection & Control: Hot-swap, redundancy, current share bus, status LED (bi-colour). Part Number: D575.00361. |
Downloads
Datasheets
cPCI 3U AC 300W Datasheet
[ cpci-3u-ac-300w.pdf, 1.72 MB, Dec.17.2025 ]
Manuals
General Safety Instruction
[ general-safety-instructions.pdf, 560.72 KB, Dec.16.2025 ]
Services
Kontron Services Brochure
[ kontron-services-brochure.pdf, 8.9 MB, Dec.17.2020 ]
