CompactPCI 1U 84HP 3 Slots Datasheet
881.46 KB | March 26, 2026
CompactPCI 2U 84HP 3 Slots
300 W cPCI PSU, removable fan tray, hot-swap
- 3 slots, 32-bit / 33 MHz, system slot left, rear I/O
- 250 W hot-swap PSU, 90–264 VAC, switch + EMI filter
- Outputs: 3.3 V/25 A, 5 V/25 A, +12 V/5 A, –12 V/1 A
- Removable fan tray, 4 fans (13.1 CFM), LEDs, left-to-right airflow
- 1U × 84HP × 283 mm, 19″ rack-mount
Product Information
This compact 3-slot CompactPCI chassis delivers efficient power and controlled cooling in a space-saving 1U form factor. Robust features, including a hot-swappable PSU and LED-monitored fan tray, ensure high reliability in rugged and industrial environments.
