Baseboard BL Pi-Tron CM4
Raspberry Pi Compute Module 4 the perfect performance boost
Mouseover Zoom loading...
Specifications
- Broadcom BCM2711, 4x ARM® Cortex®-A72, 64-bit SoC @1.5 GHz
- 1x DSI 2-lane, 1x DSI 4-lane, 1x HDMI 2.0, 1x HDMI
- Up to 8 GB LPDDR4-RAM, up to 32GB eMMC
- Optional Wi-Fi / Bluetooth®
The Pi-Tron CM4 from Kontron Electronics is a powerful single-board computer developed specifically for demanding industrial applications. It offers a flexible platform for a wide range of use cases and stands out thanks to its high compatibility with the Raspberry Pi ecosystem. Due to its architecture, the board is ideally suited for IoT and automation solutions, impressive with simple integration and the backing of a large developer community.
Performance & Architecture
The board is based on the Raspberry Pi Compute Module 4 and features a Broadcom BCM2711, 4x Arm® Cortex®-A72 64-bit SoC running at 1.5 GHz. Depending on the variant, 1 GB, 2 GB, 4 GB or 8 GB LPDDR4-3200 SDRAM is available. For data storage, the Pi-Tron CM4 supports both SD cards and eMMC storage options of 8 GB, 16 GB, or 32 GB. Through an M.2 B-Key slot with PCIe connectivity, standard modules such as Google Coral AI Edge TPU or Hailo-8™ AI modules can be integrated, enabling customized solutions for machine vision and machine/deep learning. The board can also be optionally expanded with certified Wi-Fi/Bluetooth®. Preparation for LTE modules, including SIM card and external antenna connection, allows seamless use in IoT applications.
Communication Interfaces
The Modbus-capable RS485 interface ensures reliable data exchange with other system components. The CAN bus interface supports FD (Flexible Data Rate), providing increased efficiency and higher data rates. The Raspberry Pi standard 40-PIN GPIO header offers flexible options for industrial expansions. For displays, both an HDMI slot for standard monitors and an LVDS display connection via an adapter board are available.
Application Areas & Advantages
The Pi-Tron CM4 is particularly suitable for industrial environments where reliability and flexibility are required. A key advantage is the large and dedicated Raspberry Pi community, which provides a wide range of software solutions and expansion options. All components of the board are supported by community software, ensuring quick and straightforward commissioning. Additionally, the Pi-Tron CM4 can optionally be equipped with SoftSPS CODESYS®, enabling programmable logic controller applications. The wide selection of expansion modules and high compatibility make the board an ideal solution for diverse automation and IoT projects. As a certified Raspberry Pi Design Partner, Kontron Electronics offers its customers exclusive expertise and direct access to the collective knowledge and innovations of the Raspberry Pi community.
Features
| CPU | Broadcom BCM2711, 4x Arm® Cortex®-A72, 64-bit SoC @1,5 GHz, H.265 (HEVC) bis zu 4Kp60 decode, H.264 bis zu 1080p decode, 1080p30 encode OpenGL ES 3.1, Vulkan 1.0 |
| LPDDR4-RAM | 2 GByte optional 1 GByte, 4 GByte, 8 GByte |
| eMMC | 16 GByte optional Lite/8 GByte/32 GByte (lite: without eMMC only with microSD Card) |
| EEPROM | 4 kB |
| SD CARD | CM4 Lite: 1x microSD Card Slot for Operating System, CM4 8/16/32 GByte: 1x microSD Card Slot for data (When using eMMC memory, booting from SD card is not possible.) |
| Ethernet | 1x 1 Gbit/s, 1x 10/100 Mbit/s |
| USB | 1x 2.0 Host, 1x 2.0 OTG: only to program eMMC |
| I/Os | 28x GPIO, supports up to 5x UART, 5x I²C, 5x SPI, 2x PWM, 1x SDIO (4 Bit), M.2 B-KEY 3042 (PCIe 1-lane Host, Gen 2 (5 Gbps)) |
| DIO | 4x DIO (24 V/up to 800 mA) |
| Serial | 1x RS232, 1x RS485 (Modbus-capable) |
| CAN | 1x CAN 2.0B/FD |
| WLAN/Bluetooth | Optional 2.4 GHz/5.0 GHz IEEE 802.11b/g/n/ac wireless BT 5.0, BLE |
| Touch | via I²C or USB |
| Camera Interface | 1x CSI 2-lane (MIPI Rpi-CSI0 22 pol.) |
| Power Supply | 4 V DC ±20 % |
| Power Consumption | 3.4 W...9.6 W |
| Temperature range | 0 °C ... +55 °C without condensation |
| Operating System | Raspbian Linux (not preinstalled) |
| Form Factor | 105.5 x 69.6 mm (4.3”) |
| EXTERNAL RTC | 1x on Baseboard |
| RTC BUFFERING | CR2032 |
| Debug | 1x Console |
| Approvals | CE |
