9U VME 6023 Full Size Chassis
High-capacity 21-slot 19″ VME/VME64 full-size crate (12U) with modular design, rugged construction, ultra-low noise power, advanced cooling, and comprehensive remote monitoring—engineered for sophisticated instrumentation and control systems.
- 19″ × 12U enclosure for 21 VME/VME64 cards (9U × 400 mm modules)
- Modular design: UEV 6023 bin, UEL 6020 fan tray, UEP 6021 power supply
- 1U air-compression plenum between fan tray and VME card area; power supply located behind fan tray for full rear access
- Rugged steel-aluminum bin with 5 mm thick side panels and precision countersunk rails
- UEL 6020 fan tray with 4-9 individually controlled long-life DC fans, LED display, and remote control via Ethernet/RS-232/CAN-bus
Product Information
The 9U VME 6023 Full Size Chassis is crafted for demanding applications in data acquisition, control, and test instrumentation. It supports up to 21 full-size VME or VME64 modules (9U × 400 mm) housed within a robust 12U rack chassis. Its modular architecture—including a structural bin, intelligent fan tray, and advanced power supply—enhances configurability and maintenance. The 1U air-compression chamber ensures optimal thermal performance, while rear access to the backplane remains unobstructed. Integrated environmental control and diagnostics (via LED display and remote interfaces) along with ultra-clean power delivery and programmable safety features make it an ideal platform for precision-dependent and high-reliability environments.
Technical data
| Features | Complies with VME/VME64 standard (9U × 400 mm modules) Holds 21 slots in an efficient 12U rack design Modular ""bin + fan tray + PSU"" conception for flexibility and easy servicing Intelligent fan tray with LED indicators and Ethernet/RS-232/CAN-bus monitoring High-density, low-noise switching power supply with programmable safety limits Heavy-duty steel-aluminum chassis with expanded rear access and airflow optimization |
|---|
