Coming soon
3.5"-SBC-PTL
3.5" Single Board Computer with Intel® Core™ Ultra 300 Series Processors
General Safety Instruction
628.88 KB | March 26, 2026
Coming soon
3.5"-SBC-P100
3.5" Single Board Computer with AMD Ryzen™ AI Embedded P100 Series Processors
- AMD Ryzen™ AI Embedded P100 series processor
- AI acceleration XDNA™ 2 Architecture NPU
- 2x 2.5 GbE Ethernet Controller and 2x CAN FD buses integrated
- Various expansion capabilities by board to board connector, M.2 sockets
- Industrial-grade operating temperature range, wide voltage input
Energy-Efficient & Powerful Platform for Next Gen AI Solutions
3.5"-SBC-P100 is powered by AMD Ryzen™ AI Embedded P100 Series processors with iGPU Radeon™ RDNA™ 3.5 and integrated NPU XDNA™ 2, delivering cutting-edge graphics performance and next-level AI inference acceleration. It features 2.5 GbE with TSN and dTPM 2.0 support, ensuring real-time and secure communications. Finally, the board supports a board-to-board connector and a board-to-wire connector, providing additional I/O ports and extra graphics / AI acceleration card(s) respectively without the restriction of small form factor.
Technical data
| Processor | AMD Ryzen™ AI Embedded P164 (8C, 16M, ~ 5 GHz, 15 W ← 28 W → 54 W TDP) AMD Ryzen™ AI Embedded P164i (8C, 16M ~ 5 GHz, 15 W ← 28 W → 54 W TDP) AMD Ryzen™ AI Embedded P132 (6C, 8M, ~ 4.5 GHz, 15 W ← 28 W → 54 W TDP) AMD Ryzen™ AI Embedded P132i (6C, 8M, ~ 4.5 GHz, 15 W ← 28 W → 54 W TDP) AMD Ryzen™ AI Embedded P121 (4C, 8M, ~ 4.4 GHz, 15 W ← 28 W → 54 W TDP) AMD Ryzen™ AI Embedded P121i (4C, 8M, ~ 4.4 GHz, 15 W ← 28 W → 54 W TDP) |
|---|---|
| Graphics | AMD Radeon™ RDNA™ 3.5 (2.8 / 2.8 / 2.8 / 2.8 / 2.7 / 2.7 GHz resp.) |
| AMD XDNA™ 2 (50 / 50 / 50 / 50 / 30 / 30 TOPS resp.) | |
| Main Memory | 2x DDR5 5600 SO-DIMM up to 128 GByte (Sideband ECC support) |
| Display | 1x eDP (4096 x 2304 @ 120 Hz) / LVDS (24-bit, 2-ch, 1920 x 1200 @ 60 Hz) (switchable by BIOS) 3x DP (7680 x 4320 @ 60 Hz, 2x Full-size DP on rear, 1x DP USB-C on rear) Quadruple Display |
Downloads
Technical Specification
3.5" SBC Tech Spec Sheet
14.12 MB | March 26, 2026
Success Story
Accelerated claims settlement after hail damage with AI
Related products & solutions
New product
3.5"-SBC-RPL
3.5" Single Board Computer with 13th Gen Intel® Core™ U-Series Processors
New product
3.5"-SBC-AML/ADN
3.5" Single Board Computer with Intel Atom® x7000(R)E Series, Intel® Core™ i3 N-Series & Intel® N-Series Processors
Services & Add-ons
Kontron ToolSuite
Central Management Solution for BIOS Configuration in Embedded Systems.
KontronOS
The Secure, Hardened Linux®-Based Operating System for Edge Devices
KontronAIShield
KontronAIShield for Surveillance provides real-time threat detection and intrusion monitoring using AI-powered security. It identifies and responds to both known and emerging threats, ensuring continuous protection for your surveillance infrastructure.
Advantages of Kontron Single Board Computers
Better overall specifications than competitions
One-stop-shop integration service
Stable long-term availability
Flexible customization
Quick lead time
Customer Portal
This section is exclusively for Kontron customers. After registration, you will gain access to BIOS images, Product Change Notifications (PCNs), 3D models for CAD, and software development tools.
