KBox E-210 Series Box PC Datasheet
3.34 MB | March 26, 2026
KBox E-210 Series
Fanless Box PC with 7th / 6th Gen Intel® Core™ / Celeron® U-Series Processors
- 1x DP, 1x HDMI 2.0 for display output
- 2x GbE LAN for Ethernet
- 4x USB 3.2 Gen 1, 2x RS232/422/485, 1x DIO for peripheral connection
- 1x 2.5” SATA 3.0 HDD / SSD Slot for storage
- 1x mPCIe, 1x M.2 Key B for expansion
4K Ultra HD Support
4K Support in Both Graphics Processing Capability and Data Transmission
Kontron's KBox E-210 Series is powered by 7th / 6th Generation Intel® Core™ / Celeron® U-Series processors with up to Intel® HD Graphics 620 integrated GPU inside. It has sufficient processing and graphics capability to deal with 4K Ultra HD data. Also, it is equipped with several next-generation interfaces, including two DDR4 SO-DIMM memory sockets, one HDMI 2.0 video output port and one 2.5" SATA 3.0 HDD / SSD Slot. All of them have higher bandwidth and can double the data rate in comparison with previous-generation ones. Data transmission will not be a problem anymore when a 4K file is captured from a storage device, then transferred to CPU, GPU along with memory for processing, and finally output to display.
Storage and Wireless Expansion
The KBox E-210 Series reserves space for one mPCIe socket and one M.2 Key B socket. Especially, M.2 Key B socket is a highly-integrated expansion interface and allows users to add extra SSD memory space or expand 3G / 4G wireless function.
Technical data
| Processor | Intel® Core™ i7-7600U (Dual Core, 4M Cache, 2.8 / 3.9 GHz, FCBGA1356, 15 W TDP) Intel® Core™ i5-7300U (Dual Core, 3M Cache, 2.6 / 3.5 GHz, FCBGA1356, 15 W TDP) Intel® Core™ i3-7100U (Dual Core, 3M Cache, 2.4 GHz, FCBGA1356, 15 W TDP) Intel® Celeron® 3965U (Dual Core, 2M Cache, 2.2 GHz, FCBGA1356, 15 W TDP) Intel® Core™ i5-6300U (Dual Core, 3M Cache, 2.4 / 3.0 GHz, FCBGA1356, 15 W TDP) |
|---|---|
| Main Memory | 2x DDR4 2133 1.2 V SO-DIMM up to 32 GByte |
| Graphics Controller | Intel® HD Graphics 620 (7th Gen Core™ CPU) Intel® HD Graphics 610 (Celeron® CPU) Intel® HD Graphics 520 (6th Gen Core™ CPU) |
| Display | 1x HDMI 2.0 (on rear, 4096 x 2160 @ 60 Hz) 1x DP (on rear, 4096 x 2304 @ 60 Hz) Dual display support |
| Audio Controller | Realtek ALC662 |
Downloads
Driver
KBox E-210 Series Chipset Driver for Windows
2.72 MB | March 26, 2026
KBox E-210 Series Graphics Driver for Windows
373.4 MB | March 26, 2026
KBox E-210 Series ME Driver for Windows
217.04 MB | March 26, 2026
KBox E-210 Series LAN Driver for Windows
354.82 MB | March 26, 2026
KBox E-210 Series USB 3.0 Driver for Windows 7
5.5 MB | March 26, 2026
KBox E-210 Series Audio Driver for Windows
242.39 MB | March 26, 2026
KBox E-210 Series COM Patch File
4.6 MB | March 26, 2026
